● durable break-resistant connectors
● copper terminals with anti-oxidation nickle & gold plating
● easy to see phosphorescent (glow in the dark) connector boot
● extra wide latch for quick connection/removal
● easy coil, kink resistant
when delivering digital signals matter, rgblink design cables for cat5/cat6 ethernet or led display connection provide supperior performance and reliable connectivity.
connector boots provide bend protection and includes a cover with latch extenstion making insertion and removal to equipment both easier and more dfurable. additionally the boots are phosphorescent allowing connectors to be easily identified in darkend environments.
the cable includes labelling system with clear heatshrink at both ends allowing identication labels to be fitted.
cat6 cables are available in a variery of standard ready-to-use lengths
|
conductors |
wire guage |
24awg |
|
material |
bare copper twisted pair |
|
|
cord size |
7/0.2/bczhengfy ± 0.008 |
|
|
insulation |
avg. thickness |
0.2mm |
|
min. thickness |
0.16mm |
|
|
material |
hd-pe |
|
|
conductior colors |
orange*white/orange | green*white/green | blue*white/blue | brown*white/brown |
|
|
diameter |
0.98 ± 0.03mm |
|
|
jacket |
avg. thickness |
0.6 ± 0.05mm |
|
material |
110p matte |
|
|
color |
matte black |
|
|
diameter |
6.0 ± 0.015mm |
| product code | model | item | |
|---|---|---|---|
| 940-0001-20-11-0 | cat 6 cable | 1.2m ethernet cable | |
| 940-0001-50-11-0 | cat 6 cable | 1.5m ethernet cable | |
| 940-0003-00-11-0 | cat 6 cable | 3.0m ethernet cable | |
| 940-0010-00-11-0 | cat 6 cable | 10m ethernet cable | |
| 940-0020-00-11-0 | cat 6 cable | 20m ethernet cable | |
| 940-0030-00-11-0 | cat 6 cable | 30m ethernet cable | |
| 940-0050-00-11-0 | cat 6 cable | 50m cat 6 ethernet cable | |
| 940-0100-00-11-0 | cat 6 cable | 100m cat 6 ethernet cable |
