● up to 16 (2k) x 16 (2k) inputs/ouputs or 4 (4k) x 16 (2k) (4x4 slots)
● wide range of user fit smart detect signal choices for input and output
● auto input format detect and conversion
● edid management on board
● genlock y and digital reference built in
● real-time resolution adaptation
● isolated storage and frame rate conversion
● rotation in 90°increments
● color uniformity compensation technology
● dsk and chroma key features
● dedicated source preview module (standard with hdmi and h.264)
● option for redundant hot-swap power supply
● hot backup and auto-fail over functionality
● user-defined resolution adjustments
● multi-layer / multi-window
● multi-mode - choose from video wall, presentation or dynamic routing
● xpose desktop and mobile compatible
x2 is a multiple output video processor, offering up to 16 outputs via four card-frame style slots. output signal choices include hdmi, 3g-sdi, hdbaset and h.264. on the input side there are similarly four slots, supporting up to a total of 16 video inputs. options for input include vga, cvbs, usb media, 3g-sdi, hdbaset as well as a multi-signal 4k in option.
x2 combines truly seamless, fade in fade out, glitch-free switching with advanced scaling technologies to meet the requirements of high quality, high resolution video applications, and with multi-mode operations built right in, x2 can equally be used as a video wall processor, a presentation processor or a dynamic router.
edid management is built in enabling wide signal support, and faciliting any-signal cross-conversion for output. real-time resolution adaptation, color uniformity compensation technology are also on board.
from the front panel operation check status and set ip address, them connect remotely over a lan to xpose for dynamic over-the-wire configuration of x2
x2 is a powerful yet economical solution, ideal for video wall applications, supporting multi-window, multi-layer video configurations across the output pixel space.
| connectors | input | 4 slots, up to 16 inputs, select from below
|
||||||||||||||||
| output | 4 slots, up to 16 outputs, select from below
|
|||||||||||||||||
| pvw |
|
|||||||||||||||||
| communication |
|
|||||||||||||||||
| power | 2 slots (1 psu fitted as standard
|
|||||||||||||||||
| performance | input resolutions | sdi
|
||||||||||||||||
hdmi | usb
|
||||||||||||||||||
hdbaset
|
||||||||||||||||||
vga
|
||||||||||||||||||
cvbs
|
||||||||||||||||||
h.264
|
||||||||||||||||||
hdmi | displayport
|
||||||||||||||||||
| output resolutions | select from below or configure customized sdi
|
|||||||||||||||||
hdmi | hdbaset
|
||||||||||||||||||
h.264
|
||||||||||||||||||
| supported standard |
|
|||||||||||||||||
| grey level | 10bit | |||||||||||||||||
| power | input voltage | 100v~240v, 50/60hz auto adjusted | ||||||||||||||||
| max power | 200w | |||||||||||||||||
| environment | temperature | 0°c ~ 40°c | ||||||||||||||||
| humidity | 10% ~ 85% | |||||||||||||||||
| physical | weight |
|
||||||||||||||||
| dimensions |
|
*wifi module sold separately
| product code | model | item | |
|---|---|---|---|
| 310-0002-01-0 | x2 | universal processor | |
| 950-0001-00-0 | power supply option | 200w modular psu | |
| 190-0002-02-2 | input option module | quad hdmi input module | |
| 190-0002-03-0 | input option module | tri0le vga input module | |
| 190-0002-04-1 | input option module | quad 3g-sdi input module | |
| 190-0002-05-0 | input option module | quad cvbs input module | |
| 190-0002-06-1 | input option module | quad hdbaset input module | |
| 190-0002-09-0 | input option module | quad h.264 input module | |
| 190-0002-10-1 | input option module | quad usb2.0 input module | |
| 190-0002-11-0 | input option module | 4k@30 digital input module | |
| 190-0002-22-0 | output option module | quad hdmi output module | |
| 190-0002-24-0 | output option module | quad 3g-sdi output module | |
| 190-0002-25-0 | output option module | quad hdbaset output module | |
| 190-0002-28-0 | output option module | quad h.264 output module | |
| 190-0002-50-1 | preview option module | pvw module (h.264/hdmi) |
download a full product catalogue here| lang | version | date | size | format | |||
|---|---|---|---|---|---|---|---|
| x2 | brochure | en | v1.5 | 20200110 | 2730kb |  | |
| x modules | brochure (modules) | en | v1.0 | 20170308 | 2906kb | | |
| x2 | specification | en | v1.9 | 20190701 | 557kb | | |
| input module - 4k30 digital | specification (module) | en | v1.1 | 20190701 | 393kb | | |
| input module - cvbs | specification (module) | en | v1.0 | 20170320 | 455kb | | |
| input module - h.264 | specification (module) | en | v1.0 | 20160729 | 575kb | | |
| input module - quad hdmi | specification (module) | en | v1.1 | 20190219 | 347kb | | |
| input module - sdi | specification (module) | en | v1.0 | 20170321 | 523kb | | |
| input module - usb | specification (module) | en | v1.1 | 20170628 | 441kb | | |
| input module - vga | specification (module) | en | v1.0 | 20170320 | 461kb | | |
| output module - h.264 | specification (module) | en | v1.0 | 20160729 | 660kb | | |
| output module - hdmi | specification (module) | en | v1.0 | 20170322 | 473kb | | |
| output module - sdi | specification (module) | en | v1.1 | 20181212 | 504kb | | |
| x2-standard models options | specification (module) | en | v1.0 | 20160823 | 302kb | |
| lang | version | date | size | format | |||
|---|---|---|---|---|---|---|---|
| x2 | dimension drawing | en | v1.0 | 20160121 | 196kb | | |
| x2 | quick start guide | en | v1.7 | 20190424 | 5247kb | | |
| x2 | user manual | en | v1.9 | 20190808 | 8396kb | |
| lang | version | date | size | format | |||
|---|---|---|---|---|---|---|---|
| universal processors | 3c certificate | en | v1.0 | 20151207 | 470kb | | |
| x2 | ce emc certificate | en | v1.0 | 20190704 | 826kb | | |
| x2 | ce lvd certificate | en | v1.0 | 20190617 | 729kb | | |
| x2 | fcc certificate | en | v1.0 | 20190704 | 890kb | | |
| x2 | rohs certificate | en | v1.0 | 20190710 | 749kb | |
