rgblink - x3
x3
key features

●  scalable videowall processing for large videowall with up to 8 displays or more

●  card frame videowall processing system available with 6 slots

●  scalable, field-expandable systems

●  high speed, dedicated video/graphic bus delivers real-time performance, each channel up to 4.25gbps

●  seamless switching between the inputs and display windows or layers

●  multiple cascade to create un-limit real time display resolution

●  local control panel as option

●  upload and display stored images

●  output max supports 16 layers operation, and single output max supports 4 layers

●  input module max supports 4 layers operation

●  independent h.264 ip streaming module

●  2si and sqd switchable in 4k application

●  simultaneous & multiple opteration modes

●  h.264 ip streaming for monitoring input signals and support live streaming show.







overview

x3, part of the rgblink universal processor range, is a scalable, expandable videowall processor that is dynamically configurable across a wide range of modern display applications. features high performance video scaling with one or more videos able to be displayed across a display surface of up to eight output displays..

x3 has four input slots allowing up to sixteen inputs to be install. two slots and up to eight outputs may be fitted. all inputs and outputs are modular with accepting rgblink smartslot modules including 3g-sdi, hdmi, dvi, displayport, composite, h.264 and usb media. multiple x3 processors can be cascaded to create very large display arrays. a dedicated, high-speed video/graphic bus maintains real-time performance even regardless of the signal load or type.

while x3 is ideal for videowall continuous display environments, the processor is truly multi-application with operation modes including videowall, presentation, matrix, 3d and more. all switching is seamless

control and configuration is undertaken interactively via rgblink xpose or t series control consoles.

unique encoding technology between 2si and sqd are switchable via rgblink 12g sdi input module to ensure a safety application during 4k signal process, transmission.

details
specification
diagram
dimensions
order codes
connectors input 4 slots, up to 16 inputs, select from below modules
4k@60 1 x dvi-i | 2 x hdmi-a | 1 x dp
12g sdi 4 x bnc (1 x 12g/6g or 4 x 3g)
4k@30 2 x dvi-i | 2 x hdmi-a | 2 x dp
3g sdi 8 x bnc (4 in | 4 loop)
hdmi 4 x hdmi-a
dvi 4 x dvi-i
h.264 4 x rj45
hdbaset 4 x rj45
vga 4 x db15
cvbs 8 x bnc (4 in | 4 backup)
usb 4 x usb-a
output 2 slots, up to 8 outputs, select from below modules
hdmi 4k 2 x hdmi-a
hdmi 2k 4 x hdmi-a
dvi 4 x dvi-i
hdbaset 4 x rj45
aro rotation 4 x dvi-i
preview x3p only, 2 slots standard with
  2 x dvi | 1 x rj45 (each modeul
communication
lan 1 x rj45
rs232 1 x rj11
usb 1 x usb-b
genlock/sync 1 x bnc | 1 x hdmi-a
power 2 slots (1 psu fitted as standard)
  1 x iec (each psu)
performance input resolutions sdi
smpte 480i | 576i | 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080i@59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.8/24/25/29.7/30
dvi | hdmi
smpte 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.8/24/25/29.7/30
vesa 800x600@60 | 1024x768@60 | 1280x768@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1440x900@60 | 1400x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 2048x1080@60 | 2048x1152@60 | 2560x960@60
hdbaset
smpte 720p@50/60 | 1080p@24/25/30/50/60|
vesa 800x600@60/75/85 | 1024x768@60/75/85 | 1280x768@60 | 1280x800@60 | 1280x1024@60/75/85 | 1360x768@60 | 1366x768@60 | 1400x900@60 | 1400x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 1920x1200@60 | 2048x1152@60 | 2560x812@60 | 2048x816@60
vga
vesa 800x600@60 | 1024x768@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1400x1050@60 | 1440x900@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60
cvbs
smpte 480i | 576i
h.264
  176x144 | 240x180 | 320x180 | 320x240 | 320x256 | 352x228 | 352x480 | 400x224 | 400x320 | 480x270 | 480x272 | 480x320 | 480x360| 480x480 | 544x480 | 608x448 | 640x360 | 640x480 | 704x576 | 720x404 | 720x480 | 720x540 | 720x576 | 850x480 | 1024x576 | 1280x720 | 1680x1056 | 1920x1080
4k@30
smpte 480p | 576p | 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@30
vesa 800x600@60 | 1024x768@60 | 1280x800@60 | 1280x1024@60 | 1400x1050@60 | 1440x900@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 2048x1080@60 | 2048x1152@60 | 2560x1600@60 | 3840x2160@30
4k@60
smpte 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@50/59.94/60 | 2160p@30/60
vesa 800x600@60 | 1024x768@60 |  1280x768@60 | 1280x800@60 | 1280x1024@60 | 1360x768@60 | 1366x768@60 | 1400x900@60 | 1600x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 1920x1200@60 | 2048x1080@60 | 2048x1152@60 | 2560x812@60 | 2560x960@60 | 2560x1600@60 | 3840x1080@60 | 3840x2160@30/60
12g sdi
smpte 720p@50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@23.98/24/25/29.97/30/50/59.94/60
output resolutions select from below or configure customized sdi
smpte 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 1080psf@23.8/24/25/29.7/30
dvi
smpte 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60
vesa 800x600@60 | 1024x768@60 | 1280x800@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1400x1050@60 | 1440x900@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 2048x1152@60
hdmi
smpte 720p@23.98/24/25/29.97/30/50/59.94/60 | 1080p@23.98/24/25/29.97/30/50/59.94/60 | 2160p@23.98/24/25/29.97/30/50/60
vesa 800x600@60 | 1024x768@60 | 1280x768@60 | 1280x800@60 | 1280x960@60 | 1280x1024@60 | 1360x768@60 | 1366x768@60 | 1400x900@60 | 1400x1050@60 | 1440x900@60 | 1600x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@60 | 1920x1200@60 | 2048x1152@60 | 2560x812@60 | 2560x816@60 | 2560x1600@60 | 3840x1080@60 | 3840x2160@ | 4096x2160@60
hdbaset
smpte 720p@50/59.94/60 | 1080i@50/59.94/60 | 1080p@239.98/24/25/29.97/30/50/59.94/60
vesa 1024x768@60/75/85 | 1280x768@60 | 1280x800@60 | 1280x1024@60/75/85 | 1360x768@60 | 1366x768@60 |1400x900@60 | 1400x1050@60 | 1600x1200@60 | 1680x1050@60 | 1920x1080@ 60 | 1920x1200@60 | 1920x1080@60 | 2560x812@60 | 2048x816@60
h.264
  176x144 | 240x180 | 320x180 | 320x240 | 320x256 | 352x228 | 352x480 | 400x224 | 400x320 | 480x270 | 480x272 | 480x320 | 480x360 | 480x480 | 544x480 | 608x448 | 640x360 | 640x480 | 704x576 | 720x404 | 720x480 | 720x540 | 720x576 | 850x480 | 1024x576 | 1280x720 | 1680x1056 | 1920x1080
supported standard
sdi smpte st 2082-1 | smpte st 2081-1 | smpte st 424 | smpte st 292-1 | smpte st 259 | dvb-asi | madi
hdmi 2.0
dp 1.2
dvi dual link
hdbaset 1.0
grey level 12bit
color space 4:4:4
power input voltage ac 100v~240v, 50/60hz
max power 205w
environment temperature 0°c ~ 55°c
humidity 10% ~ 90% rh
physical weight
net (device) 12.3kg
packaged 20.4kg
dimensions
net (device) 485mm x 387mm x 135mm
packaged 635mm x 545mm x 275mm
product code model item
310-1003-11-0 x3p 16x8 universal processor
310-0003-01-0 x3 touch 16x8 universal processor (with touch screen)
310-0003-11-0 x3 16x8 universal processor
310-0003-16-0 x3e 16x8 universal processor (2k only)
190-0003-01-0 input module option quad dvi input module
190-0003-02-0 input module option quad hdmi input module
190-0003-03-0 input module option quad vga input module
190-0003-04-0 input module option quad sdi input module
190-0003-05-0 input module option quad hdmi-s input module
190-0003-06-0 input module option quad cvbs input module
190-0003-07-0 input module option quad usb2.0 input module
190-0003-09-0 input module option quad hdbaset input module
190-0003-11-0 input module option 4k@30 digital input module
190-0003-13-0 input module option quad h.264 streaming input module
190-0003-14-0 input module option 4k@60 digital input module
190-0003-15-0 input module option quad hdmi-de input module
190-0003-16-0 input module option quad 3g-sdi s input module
190-0003-17-0 input module option 12g-sdi input module
190-0003-21-0 output module option quad dvi output module
190-0003-22-0 output module option quad hdmi output module
190-0003-23-0 output module option quad vga output module
190-0003-24-0 output module option quad 3g-sdi output module
190-0003-25-0 output module option quad hdbaset output module
190-0003-27-0 output module option quad h.264 output module
downloads
literature
documents
certifications
software
firmware
download a full product catalogue here

lang version date size format
x3brochureenv1.6202001102170kb.pdf
x3pbrochureenv1.4201904172923kb.pdf
x modulesbrochure (modules)env1.0201703082906kb.pdf
x3specificationenv1.420190729601kb.pdf
x3especificationenv1.120190729610kb.pdf
x3pspecificationenv1.220200325809kb.pdf
input module - 12g sdispecification (module)env1.020190401301kb.pdf
input module - 4k30 digitalspecification (module)env1.020170405503kb.pdf
input module - 4k60 digitalspecification (module)env1.320190814317kb.pdf
input module - cvbs specification (module)env1.020170405521kb.pdf
input module - d-hdmi specification (module)env1.220191225248kb.pdf
input module - d-sdi specification (module)env1.020181101415 kb.pdf
input module - dvi specification (module)env1.020170405500kb.pdf
input module - h.264 specification (module)env1.020181120555kb.pdf
input module - hdbasetspecification (module)env1.020181114568kb.pdf
input module - hdmi specification (module)env1.020170405535kb.pdf
input module - sdi specification (module)env1.020170406656kb.pdf
input module - usb specification (module)env1.120170628526kb.pdf
input module - vga specification (module)env1.020170406520kb.pdf
output module - 2k dvispecification (module)env1.020190219337kb.pdf
env1.020181219669kb.pdf
output module - h.264specification (module)env1.120191108334kb.pdf
output module - hdbasetspecification (module)env1.020181114594kb.pdf
output module - hdmi specification (module)env1.020170405492kb.pdf
output module - hdmi 2.0specification (module)env1.120190629285kb.pdf
output module - sdi specification (module)env1.020170406502kb.pdf
preview modulespecification (module)env1.120190814333kb.pdf
lang version date size format
x3dimension drawingenv1.020160125168kb.pdf
x3 expressquick start guideenv1.0201511251968kb.pdf
x3 touchquick start guideenv1.4201512022715kb.pdf
x3user manualenv1.5201904164783kb.pdf
x3 expressuser manualenv1.0201501064.2mb.pdf
x3puser manual env1.0201911075249kb.dmg
lang version date size format
x33c certificateenv1.020151207470kb.pdf
x3ce emc certificateenv1.020190704826kb.pdf
x3ce lvd certificateenv1.020190617729kb.pdf
x3fcc certificateenv1.020190704890kb.pdf
x3rohs certificateenv1.020190710749kb.pdf
xpose logox3 is configurable and controllable from xpose. download the latest release of xpose here
no specific software for x3
while xtools is packaged with firmware when released, we nonetheless recommend downloading the latest version of the xtools update tool here.
lang version date size format
x3p(by xpose 2.0)firmwareenv3.722020031057.28mb.zip
x3(by xpose 2.0)firmwareenv3.722020031057.28mb.zip
x3p(by xpose 1.0)firmwareenv2.652019052841.4mb.zip
x3(by xpose 1.0)firmwareenv2.652019052841.73mb.zip
*some products pictured with optional modules and accessories. refer to specifications and guides for details.
}
